FDG410H Hybrid VTOL Fixed-wing long UAV endurance 10hours with 5kg

FDG410H Hybrid  long  endurance UAV can flight 10hours with 5kg payload. it’s upgrated from FDG410 electirc drone, wingspan 4m, drone weight 25kg, max takeoff weight 40kg, only need one people assembly with 5 mins can flight without tool, there are navigation lights on the left and right wing, so you can flight even at night. it’s good for surveying and mapping, border patrol, forest fire prevention etc.

Specifications

Drone type: Hybrid VTOL drone
Size（wingspan*length*heigh）: 4000*2060*768mm

Drone weight: 25kg without fuel
Max. takeoff weight: 40kg

Engine: B2G70

Fuel consumption: 1.1L/H
Max. payload: 10kg(without fuel)

Max flight time: 10h/5kg
Max. climb speed(fixed-wing): 4 m/s
Max. descent speed(fixed-wing): 5 m/s
Suggest cruise speed: 85 km/h
Max cruise speed: 130 km/h
Max. flight altitude: 3500 m
ceiling limited: 5000 m
Wind resistance level: 6
Operation Temp.: -20～60℃

IP: 54
VTOL battery: 12S 8000MAH*2

Engine battery:6s 10000mah*1
Packing Size: L 1560 *W630 *H817cm
