MAD 3506 EEE brushless drone motor
MAD 3506 EEE brushless drone motor
It is widely used for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor.
MAD 35 series motors are the classic UAV motors for small to medium industrial use, efficient and for long endurance flights. These sizes of motors have been on the market for 10 years, MAD Components has optimised them to be very lightweight.
| Motor Model | MAD 3506 EEE V3.0 | Number of pole pairs | 7 | ||||||
| Stator | Anticorrosive | Varnished wire Degree | 150°C | ||||||
| Motor Size | D:42.5 × 23.8 mm | Magnet Degree | 150°C | ||||||
| Degree of Protection | Â Rain protection | Cable Length | 150 mm 18# Awg(Black) silicone | ||||||
| Centrifugal Heat Dissipation | Independent | Rotor Balance | ≤5 mg | ||||||
| Propeller Mounting Holes | D:12 M3×4 | Motor Balance | ≤10 mg | ||||||
| Shaft Diameter | IN: 4 mm | Motor Mounting Holes | D:25 M3×4 | ||||||
| Bearing | EZO 694ZZ*2 | Disruptive test | 500 V | ||||||
