MAD 4006 EEE brushless motor
MAD 4006 EEE brushless motor
MAD 40 series motors are the classic UAV motors for small to medium industrial use, efficient and for endurance flights. Motors of this size have been on the market for 10 years, MAD Components has optimised them to be very lightweight.
| Specification | |||||||||
| Motor Model | MAD 4006 EEE V1.0 | Number of pole pairs | 12 | ||||||
| Stator | Anticorrosive | Varnished wire Degree | 150°C | ||||||
| Motor Size | D:44.5 × 24.1 mm | Magnet Degree | 150°C | ||||||
| Degree of Protection | Rain protection | Cable Length | 150 mm 18# Awg(Black) silicone | ||||||
| Centrifugal Heat Dissipation | Independent | Rotor Balance | ≤5 mg | ||||||
| Propeller Mounting Holes | D:12 M3×4 | Motor Balance | ≤10 mg | ||||||
| Shaft Diameter | IN: 4 mm | Motor Mounting Holes | D:19 M3×4, D:25 M3×4 | ||||||
| Bearing | EZO 694ZZ*2 | Disruptive test | 500 V | ||||||
