MAD 5008 IPE V3 brushless motor
MAD 5008 IPE V3 brushless motor
5008 as the first motor was designed and developed by MAD EU in 2015, the result never let the motor designer and user disappointed. It is the most efficient motor equipped with 18-20inch propeller, the best option for the multirotor need 1-2kg/rotor.It is widely used for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor.
| Motor Model | MAD 5008 IPE V3.0 | Number of pole pairs | 14 | ||||||
| Stator | Anticorrosive | Varnished wire Degree | 180°C | ||||||
| Motor Size | D:56 × 29.3 mm | Magnet Degree | 150°C | ||||||
| Degree of Protection | IP45 | Cable Length | 150 mm 16# Awg(Black) silicone | ||||||
| Centrifugal Heat Dissipation | YES | Rotor Balance | ≤5 mg | ||||||
| Propeller Mounting Holes | D:12 M3×4,  D:15 M3×4 | Motor Balance | ≤10 mg | ||||||
| Shaft Diameter | IN: 6 mm | Motor Mounting Holes | D:25 M3×4 | ||||||
| Bearing | EZO 696ZZ*2 | Disruptive test | 500 V | ||||||
