MAD Antimatter M6C06 EEE brushless drone motor
MAD Antimatter M6C06 EEE brushless drone motor
Antimatter M6C06 is designed to carry a payload of 1.5-2.5kg and supports 6S, 8S, 12S voltages.
ENTHUSIASTS EXTREME EDITION for extreme weight reduction without compromising performance.
Maximum hollow design, ultra-light weight, fast heat dissipation
Unique stator design, 24N28P configuration
Passed the simulation test of magnetic flux density, ensuring the motor in lower energy consumption.
| Motor Model | MAD M6C06 EEE V2.0 | Number of pole pairs | 14 | ||||||
| Stator | Anticorrosive | Varnished wire Degree | 180°C | ||||||
| Motor Size | D:72 × 27.4 mm | Magnet Degree | 150°C | ||||||
| Degree of Protection | Rain protection | Cable Length | 60 mm 16# Awg(Black) silicone | ||||||
| Centrifugal Heat Dissipation | Independent | Rotor Balance | ≤5 mg | ||||||
| Propeller Mounting Holes | D:12 M3×4,D:18 M3×4,D:22 M3×4 | Motor Balance | ≤10 mg | ||||||
| Shaft Diameter | IN: 6 mm | Motor Mounting Holes | D:25 M3×4, D:32 M4×4 | ||||||
| Bearing | EZO 696ZZ*2 | Disruptive test | 500 V | ||||||
